Condenser Design Shell and Tube Condenser Design (CnD) is a software that is made to demonstrate thermal analysis and design calculations required for designing shell and tube condensers. This software can design, horizontal shell side condensers, horizontal tube side condensers, vertical shell side condensers, vertical tube side condensers and reflux condensers. This software application is intended for use by professional and academics in the engineering industry. Some basic understanding in thermodynamics, fluid flow and shell & tube heat exchangers is required before attempting to use this tool. Below is a list of main features: 1. Support S.I Units and English (U.S) Units of measurement 2.
Unit Converter includes 23 measurements units with 200 unit conversion 3. Import physical properties data to hot side and cold side from Microsoft Excel & from WeBBusterZ Physical properties database (included!) 4. Save/Load results Results 5. Generate an engineering datasheet (can be exported to.pdf file format), Export Results to Engineering Data sheet in Microsoft Excel for editing 6.
The Condenser Performance Test and Thermal. The calculation of condenser cleanliness coefficient. Seawater volume flow and condenser design. In either design, there is an approach temperature, which is the temperature. Condenser tubes at low velocity (3.51 ft/s [1.07 m/s]) and hi gh water hardness.
Export Results summary to Microsoft Word or Print Results summary. Calculations 7. Supports Horizontal shell side/Horizontal tube side/Vertical shell side/Vertical tube side and Reflux condensers design. Supports Full condensation and Partial condensation (Subject to condensation model selection please see the table provided below for full information). Support Sub cooling, Superheated vapor, Zone analysis, Shear Controlled and Gravity Controlled condensation (Subject to condensation model selection please see the table provided below for full information).
Basis and assumptions that the software makes during the calculations are stated on a visible panel. Support single phase vapour condensation on hot side and liquid coolant on cold side, bare tubes only 12. TEMA designations. Ability to calculate unknown Cold side temperature, Unknown Hot or cold side flow rate. Triangular and square pitch tube orientation 15. Detailed calculation than displays many calculated variables such as: Duty, Area, Number of tubes, Shell/Tube velocities, flooding velocity and operating velocity for reflux condenser, Reynolds numbers, Condensation heat transfer coefficient, Condensation flow regime, Number of Baffles and Baffle spacing, Scale resistance (dirt factor), Overall heat transfer coefficient for both Clean and Fouled conditions, Pressure dropsetc. Chained convict for life book one download.
Pdf File Condenser
And many more 16. Ability to track calculation changes from trial to another. Included Databases: 17. Estimate the Physical properties of pure components for more than 1450 components; the database has the ability to estimate Thermal Conductivity, Density, Heat Capacity and Viscosity. Riconoscimento di debito fac simile download. The database also included critical properties, boiling and melting points and come as separate software but easily integrated with the software.
Ability to add your own properties in the additional user databases. Tube counts and standard tube sizes tables 20.
Steam Condenser Design Calculation Example
Fouling factors 21. Overall heat transfer coefficients 22. Material Thermal Conductivities. Maximum Allowable design velocities inside tubes for liquids 24. Ability to add your own components to use for simulations.
